Home  > Antenna&RF Cables
  • SMA Bulkhead crimp jack,rear mount sealed ip67 compliant (for 1.13mm)

SMA Bulkhead crimp jack,rear mount sealed ip67 compliant (for 1.13mm)

  • Part No.:CB2009-081
  • MOQ:100
  • SMA UFL
  • IPEX 1.13MM
  • Product description: Jack RP SMA female bulkhead to IPEX UFL with 1.13 cable customize length​
  • Inquiry

PRODUCT INTRODUCTION


SMA Bulkhead crimp jack,rear mount sealed ip67 compliant (for 1.13mm)

Jack RP SMA female bulkhead to IPEX UFL with 1.13 cable customize length


Connector on first  SMA male connector
Connector on second SMA female right angle connector
Cable type RG174 or RG316
Cable length Can be customized
Packing Neutral packing or customized
Temperature Range -55~+155°C (PE Cable -40~+85°C)
Impedance 50Ω
Vibration 98m/S2 (10~2000Hz), 10g
Frequency Range DC-12.4GHz(semi-rigid cable DC-18 GHz)
Insertion Loss  ≤ 0.15dB/6GHz
Withstanding Voltage  1000V r.m.s   at sea level
Working Voltage 335Vr.m.s   at sea level
Insulation Resistance  ≥ 5000 MΩ
Durability ≥ 500(cycles)
Contact resistance:  CenterContact   ≤ 3mΩ
Outer Contact   ≤ 2.5mΩ

Voltage Standing Wave Ratio:Straight
flex cable          ≤ 1.10+0.02f
Semi-rigid cable     ≤ 1.07+0.018f

Right angle
flex cable         ≤ 1.20+0.03f
Semi-rigid cable   ≤ 1.17+0.02f
