Right angle RF cables SMA to SMA LMR240
- Part No.:CB2009-080
- MOQ:100
- RF Cables
- SMA LMR240
- Product description: Right angle RF cables SMA to SMA LMR240
PRODUCT INTRODUCTION
Right angle RF cables SMA to SMA LMR240
Mechanical Characteristics
Characteristic Impedance:50ΩFrequency Range:0-11GHz
Wishstanding Voltage: ≥750-1500V,50Hz
Working Voltage: ≥250-500V,50Hz (see level)
≥65-125V,50Hz (Height 21000M)
Insulation Resistance: 5000mΩ
Insulation Resistance: Inner conductor: ≤5mΩ
Outer conductor: ≤5mΩ
RF leakage(1GHZ):Flexible: ≥60dB
Semi-rigid cable: ≥70dB
Material
Pin conductor:Brass/Beryllium copper--Gold plated
Beryllium copper--Gold plated
Stainless steel--Passivation
Brass--Gold plated / Ternary Alloy (Cu+Zn+Sn)
Body / Outer conductor:Phosphor bronze --Gold plated
Plug:Beryllium copper / Phosphor bronze--Gold plated
crimping sleeve:Brass--Gold plated
Insulator:PTFE / PFA
Sealing:Silastic
